Combine Harvester

2250000.00 INR/Set

Get a Price/Quote

Product Details:

Product Type Agricultural Machine
Technology Other
Power Source Diesel
Operating Type Automatic
Power 100 Horsepower (HP)
Dimension (L*W*H) 5180x2585x2720 Millimeter (mm)
Warranty One Season
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

Combine Harvester Price And Quantity

Price 2250000.00 INR/Set
Minimum Order Quantity 1 Set

Combine Harvester Product Specifications

Power Source Diesel
Operating Type Automatic
Technology Other
Warranty One Season
Dimension (L*W*H) 5180x2585x2720 Millimeter (mm)
Usage & Applications Rice Harvesting
Product Type Agricultural Machine
Power 100 Horsepower (HP)

Combine Harvester Trade Information

Supply Ability 10 Set Per Month
Delivery Time 10 Days
Main Domestic Market All India

Product Description

Product Specification :

Model	OS-4LZ-100W
Type	Full-feed, Track Combine
Brand	Osaka
Overall dimension	Length x Width x Heights (mm ): 5180x2585x2720,
Weight (kg)	3750
Feeding Capacity (kg/s)	5
Harvesting Capacity (hm²/h)	0. 5-1
Engine	Engine Model: 4D352ZT32/1004
	Rated Power ( kw/hp ): 73/100
	Engine Type: Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel. Turbocharged Engine
	Rated Rotation Speed (r/min) : 2400
Driving System	Crawlers(mm): 5509054
	Minimum Ground Clearance (mm): 370mm
	Type of Gearbox: Hydraulic type + HST(3F, 3R) 42CC
	Theoretical Operating Speed (km/h ): 2-7
	Type of Brake: By Foot.
	Steering: Clutch and Brake.
Cutting header	Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 944; Nos: 5
	Height Adjustment: Hydaulics.
	Cutting Bar Length (mm ): 2200
	Type of Cutting Bar Auger: Screw Conveying.
	Type of Blade: V Type / Left and Right.
	Rape Seed Extension: Optional
Threshing & Separating	Threshing System: Spiked Tooth Axial Flow
& Cleaning System	Threshing Cylinder Size Diameter x Length (mm ): 626X2000
	Reshresher: Blade Rotation.
	Vibrating Sieve: Adjustable Sieve/ Meshing Sieve/Hole sieve(Optional)
	Fan: Type: Swirl; Diameter( mm ): 405; Nos: 4
Grain Storing	Option 1: Grain Tank with unloading Auger ,Capacity(L):1500
Grain Storing	Option 2: Manual Operation.
